Tower Cran Cran Court Cable YCW 3 × 120 + 1 × 35

Tower Cran Cran Court Cable YCW 3 × 120 + 1 × 35

Get Latest Price

To'lov turi:	L/C,T/T,D/P,Western Union
Inkoerm:	FOB,CFR,CIF,EXW
Min. Buyurtma:	100 Meter
Tashish:	Ocean
Port:	Dalian

Endi murojaat qiling

Mahsulot tavsifi

Mahsulot xususiyatlari

Mahsulot tavsifi

Mahsulot xususiyatlari

Model raqami: YCW 3×120+1×35

Origin: Xitoy

Sertifikatlash: GB/T 5013-2008.JB/T 8735-2011.IEC 60245:2003

Mahsulot tavsifi

YCW turi minorasi kran kabelining xususiyatlari

1. Minora kran kranining elektr kabeli AC 450 / 750V narxli kuchlanishga nisbatan qo'llaniladi.
2. Kabel o'tkazgichlarining uzoq muddatli ishlash harorati 60 ° dan yuqori emas.
3. Atrof-muhitdan foydalanish harorati -40-50 ℃.
4. Tower kran kodi Ob-havoning qarshiliklari va ochiq havoda va neft kontaktlari uchun mos keladigan neft qarshiligi.
5. Kabel sinovi: 2500 V Justgedan 8 tagacha kabel 5 minutni buzmasdan davom etishi mumkin.

Minora kranining quvvati parametrlari

Cores×Cross section mm²	Mean Outside Diameter mm		Cores×Cross section mm²	Mean Outside Diameter mm
Cores×Cross section mm²	lower limit	upper limit	Cores×Cross section mm²	lower limit	upper limit
1×120	22.8	28.6	3×25+1×10	27.3	34.5
1×150	25.2	31.4	3×35+1×10	29.9	37.8
1×185	27.6	34.4	3×50+1×16	34.8	43.9
2×70	35.8	45.1	3×70+1×25	39.8	50.1
2×95	40.2	51	3×95+1×35	44.8	56.4
3×95	43.3	54	3×120+1×35	48.5	61
3×120	47.3	60	3×25+2×10	28.6	36.1
3×150	52	66	3×35+2×10	31	39.1
4×50	37.7	47.5	3×50+2×16	36.1	45.5
4×70	42.7	54	3×70+2×25	41.7	52.5
4×95	48.4	61	4×25+1×10	30.5	38.5
4×120	53	66	4×35+1×10	33.8	42.6
5×25	32	40.4	4×50+1×16	39.2	49.4
5×35	33.4	42.1	4×70+1×25	44.9	56.4
5×50	38.5	48.5	4×95+1×35	50.7	63.7
